KS-33NT AIS Tracking Device

Enhanced Safety with ONWA KS-33NT AIS Tracking Device





KS 33NT AIS

FEATURES

  • Easy tracking and retrieval
  • ONWA Encrypted technology
  • Customizable: Specifications and usage design can be customizable depending on the application Such as: low battery alarm, geo-fence, GPS lost alarm, AIS SART, etc.
Snipaste 2024 09 25 13 44 30
Snipaste 2024 09 25 13 45 04

Dimensions:

Snipaste 2024 09 25 13 14 00

Standards:

IEC-62287 IEC 62287-2 Ed. 2.0:2017

Position update:

Every 3 minutes

Working frequency:

161.975MHz / 162.025MHz

Output power:

34.8dBm±1.5dBm

Channel bandwidth:

25 KHz

Modulation mode:

GMSK

Bit Rate:

9600b/s±50ppm(GMSK)

Transmit Power:

4W, 6.5W, 12.5W (specify when ordering)

Working Voltage:

7.4V (for 4W and 6.5W version), 12V for 12.5W version Working Temp : -20~60℃

Housing Color:

Orange (4W), Orange (6.5W), Yellow (12.5W) Housing material : High quality ABS

Indicator LED:

Status and battery indication

Dimension:

315mm(H), 85mm(Diameter, max)

Weight :

400g (Include battery)

Working hour:

360 hours continuously

Waterproof:

IPX7

Technology :

AIS

Battery:

Rechargeable Lithium
